Giada F106D Mini PC | Intel Celeron N5100 | 4GB LPDDR4 RAM | Fanless | Intel UHD Graphics | 4K HDMI/DP | Win 10/11 Linux

FEATURES:

• Intel® Celeron® N5100 Processor


• 1 x DP, 1 x HDMI, Supporting 4K Display


• Onboard LPDDR4 4GB


• 2 x RJ45 Gigabit LAN and 1 x E-Key M.2 (2230) for Wi-Fi/BT


• Long life cycle


• Fanless Design

SPECIFICATIONS:

• Processor:


• CPU: Intel® Celeron® N5100 processor (Fanless)


• Turbo Frequency: 2.80 GHz/2.90 GHz


• Chipset: SoC


• Processing Units: 4 Cores/4 Cores


• Memory:


• Type: Onboard LPDDR4-2666 MHz


• Size: 4GB


• Storage Supported:


• Socket 1: 1 x M-Key M.2 (2242/2280) for SSD (only PCIe SSD)


• Socket 2: 1 x Full-size Mini-PCIe for MSATA


• Graphics:


• GPU: Intel® UHD Graphics


• Graphic Engine: DirectX 12.1, OpenGL 3.0, OpenCL 1.1, OpenGL ES 2.0, H.264, MEPG2


• DisplayPort: 1 x DP (Max.4096 x 2160 @60 Hz)


• HDMI: 1 x HDMI (Max.4096 x 2160@60Hz)


• Network:


• Controller: Realtek RTL 8111H Gigabit Ethernet


• Interface: 2 x RJ45


• Wi-Fi/BT: 1 x E-Key M.2 (2230) for Wi-Fi/BT Support Wi-Fi 5, Wi-Fi 6


• Mobile Network: 3G/4G colay with 1 x Mini-PCIe for MSATA, 1 x SIM Slot


• I/O:


• USB: 2 x USB3.2 Gen2, 4 x USB2.0


• Serial Port: 1 x RS232


• Audio: 1 x MIC-IN, 1 x AUDIO-OUT


• Antenna: 2 x Connector for Wi-Fi/BT, 1 x Connector for 3G/4G (Reserved)


• Button: 1 x Power on, 1 x CLR-CMOS


• System:


• TPM: TPM2.0


• Watchdog Timer: Yes


• Auto Power on: Yes


• RTC: Set up independently every day


• Remo on: Yes


• Fanless: Yes


• Operation System:


• Windows: Windows 10 (64Bit), Windows 11 (64bit)


• Linux: Linux Ubuntu (64bit)


• Power:


• Power Type: DC-IN


• Input Voltage: 19V/2.37A


• Environment:


• Operating Temperature: 0°C ~45°C (32°F~113°F) @0.7m/s Air Flow


• Relative Humidity: 95% @ 45°C (non-condensing)


• Certification: CE, FCC Class B


• Construction: Metal


• Fanless: Yes


• Colour: Black


• Dimensions: 18.9 x 14.8 x 2.6 cm

WHAT’S IN THE BOX:

• Giada F106D Intel Celeron Ultra-compact Fanless Player 4 GB – Black x1


• Wi-Fi Antenna x2


• AC Power Adapter x1


• Power Cable x1


• User Manual x1
